Performance | Image Sensor | 640×480 CMOS | |
Illumination | White LED | ||
Aiming | Red LED (625nm) | ||
Symbologies | 2D | PDF417, Micro PDF417, Micro QR, QR Code, Data Matrix, Aztec. |
|
1D | Code 11, Code 128, Code 39, GS1-128 (UCC/EAN 128), AIM 128, ISBT 128, Codabar, |
||
Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-8, EAN-13, ISBN/ISSN, |
|||
Interleaved 2 of 5, Matrix 2 of 5, Industrial 25, ITF6, ITF-14, Standard 25, China Post 25, |
|||
MSI Plessey, Plessey, GS1 Databar (RSS). | |||
Resolution | ≥3mil (Code 128) | ||
Typical Depth of Field | EAN-13 | 50mm-260mm (13mil) | |
Code 39 | 50mm-115mm (5mil) | ||
PDF 417 | 50mm-120mm (6.7mil) | ||
Data Matrix | 35mm-125mm (10mil) | ||
QR Code | 30mm-170mm (15mil) | ||
Scan Angle | Pitch | ±55° (QR 15mil) | |
Roll | 360° (QR 15mil) | ||
Skew | ±55°(QR 15mil) | ||
Field of View | Horizontal 45°, Vertical 34° | ||
Min. Symbol Contrast | 20% | ||
Physical | Interfaces | RS-232, USB | |
Dimensions (L×W×H) | 145×101×68mm | ||
Weight | 111g | ||
Notification | Beep, LED indicator | ||
Operating Voltage | 5VDC±5% | ||
Rated Power Consumption | 950mW (typical) | ||
Current @ 5VDC | Operating | 190mA (typical), 201mA (max.) | |
Idle | 35mA | ||
Environmental | Operating Temperature | -20°C to 60°C (-4°F to 140°F) | |
Storage Temperature | -40°C to 70°C (-40°F to 158°F) | ||
Humidity | 5% ~ 95% (non-condensing) | ||
ESD | ±15 KV (air discharge); ±8 KV (direct discharge) | ||
Drop | 1.2m | ||
Sealing | IP42 | ||
Certifications | FCC Part15 Class B, CE EMC Class B |
